How is PCD made?

Polycrystalline Diamond (PCD) or PCD tools is diamond grit fused together under high pressure and high-temperature conditions in the presence of a catalytic metal.

PCD manufacturing applies in the process of cutting materials such as aluminium, brass and copper, graphite and non-metal materials.

So, special PCD inserts are ideal if you want to obtain high abrasive resistance and high hardness. They result in a longer lifespan of the cutter and do well with customising designs to fit the exact measurement specifications.

What are PCD automotive cutting tools?

The automotive industry revolves around PCD drills and reamers. And, these cutting tools manufacture the best auto parts making the automotive industry capital of the world.

As for the PCD automotive wheel tools, you need more than a PCD drill bit and reamers. So, here are the PCD tools to manufacture wheels.

How are aluminium wheels made?

The machining of aluminium wheels using wheel repair machines require the designing and manufacturing of specific automotive wheel tools.

Machining cast aluminium wheels can be a demanding application requiring a strong steel body and uniform design. So, being in the automotive industry you will need hardened steel bodies from the start to finish machining centres.

Then, you will be able to place mechanical chip breakers nearly anywhere on the PCD tools modifying the body geometry quickly. And, you will get to turn around new and regrind tools on demand.

This allows us to place mechanical chip breakers nearly anywhere on the tool, modify body geometry quickly.

And get a remarkable turnaround of new and regrind tools on demand.

PCD Right Hand Tool

The PCD right-hand tool is the best choice for manufacturing rims with lips. The reason being, the PCD tool is designed to easily reach the corners of the inside lips during the machining process.

PCD Neutral Tool

PCD Neutral Tool is usually used when manufacturing flat rims that come with no lips. For any rim designs that want to go with simplicity, you can get the best of it using this PCD tool.

PCD Left Hand Tool

If you’re looking to design rims that have a rising centre hub, we recommend you the PCD left-hand tool. This PCD tool comes with a special feature in which the tip of the tool cuts the cone perfectly making the rising centre hub.

PCD left hand tool is needed only when you want to create the rising centre.

Round Bit Tool

With the help of a round bit tool holder, you can machine rims with a curved profile. These PCD diamond cutting tools specialize in making curved wheel rims creating a unique look.

PCD Boring Bar Style Tool

A regular right-hand tool is 6 inches long and is not suitable for machine deep rims. So, a boring bar style tool that comes 12 inches long is the best fit to reach deeper positions.

Also, the cutting tip of the boring bar is at the centre of the tool holder. So, you need a shim block to raise the cutting tip to the centre of the lathe.

Besides, you can machine the back part of the rim using an angled boring bar for better finishing.

There are various angles of this tool in the market but the most common is the 12 inches long boring bar. It comes with a negative 17.5 degree angle that perfectly machines a straight surface.

PCD Lip Cutting Tool

After machining the lips of rims according to their designs, you will need to refinish the back of the lips, either side or both sides.

And, when completing the refinishing process, a special lip cutting tool holder is needed. The lip cutting tool needs to be locked holding the rim with three bolts as safety measures.

PCD Automotive Tools Supplier Malaysia

We suggest you consult ASIME, one of the top ISO PCD tooling manufacturers with more than 20 years of experience. We speak all high-end precision tools manufacturing including PCD and CBN tools.

So look no further as we take great care in our PCD tools manufacturing process, and are always following DOE and ISO standards. We ensure that our tools and services are nothing short of world-class.

The automotive industry demands extreme precision, high-speed machining capability, and long tool life.

To meet these requirements, manufacturers rely heavily on PCD tools and advanced diamond cutting tools for consistent, high-volume production.

From aluminum engine blocks to gearbox housings, PCD cutting tools are essential for achieving tight tolerances, superior surface finishes, and reduced machining downtime.

What is a PCD cutting tool?

A PCD cutting tool is made from Polycrystalline Diamond (PCD), a synthetic diamond material sintered under high pressure and temperature.

It is bonded onto a carbide substrate to create an extremely hard and wear-resistant cutting edge.

What Materials are PCD Tools Used for?

• Aluminum alloys
• Brass and copper
• Graphite
• Composites
• Non-ferrous materials
• High-silicon aluminum

Why Use PCD Tools?

For manufacturers in automotive machining, PCD cutting tools are the preferred solution compared to conventional carbide tools.

• Exceptional hardness and abrasive resistance
• Longer tool life
• Higher cutting speeds
• Reduced tool change frequency
• Improved surface finish
• Lower production cost per part

Uses of PCD Tools in the Automotive Industry

PCD tools are widely used in automotive production because they deliver outstanding surface finishes and excellent productivity in high-speed CNC machining environments.

Automotive Components Machined with PCD Tools

• Engine blocks
• Cylinder heads
• Gearbox housings
• Brake discs
• Wheel hubs
• Pistons
• Crankshaft casings
• Camshaft components

PCD Grain Size and Application

Different grain sizes are engineered for specific automotive machining requirements.

Selecting the correct PCD grade ensures optimized tool life, better chip control, and improved machining efficiency.

What are PCD Inserts Used for?

PCD inserts are especially valuable in high-volume automotive machining where consistency and minimal downtime are critical.

• Turning aluminum components
• Milling gearbox housings
• Boring cylinder heads
• Grooving automotive parts
• High-speed finishing applications

Automotive Cutting Tool Solutions

PCD Reamers

PCD reamers are used for precision finishing of pre-drilled holes in aluminum and non-ferrous automotive parts.

They are widely used in machining valve bodies, transmission components, and engine housings.

PCD Drills

PCD drills are essential for both roughing and finishing hole operations in automotive production.

These tools ensure improved hole accuracy, better roundness, and consistent surface quality.

PCD Tools for High-Grade Automotive Parts

The demand for diamond cutting tools continues to rise as automotive manufacturers shift toward lightweight aluminum components, high-silicon alloys, composite materials, and high-speed automated machining lines.

PCD tooling supports milling, turning, boring, reaming, and high-speed finishing.

Its ability to maintain edge sharpness over long production runs significantly reduces downtime and tooling cost.

Choose the Right Automotive PCD Tools Manufacturer

PCD tools and diamond cutting tools play a critical role in automotive machining, where precision, durability, and productivity are essential.

However, performance depends not only on selecting the correct PCD grade, but also on working with the right manufacturer.

A reliable PCD tools manufacturer should provide:

• ISO-certified manufacturing standards
• Custom tool design and engineering support
• Proven experience in automotive machining
• High-speed CNC application expertise
• Consistent quality and repeatability

At ASIME, we support automotive producers with precision-engineered PCD tools and diamond cutting tools tailored to specific production requirements.

Our technical team works closely with you to ensure the right geometry, grade, and configuration for maximum efficiency.

How are Auto Parts Produced?

The automotive industry is constantly developing with innovation that demands long-lasting auto parts. More than that, the ultimate performances of the auto parts must excel. Therefore, parts processing factory requires PCD automobile tools and CBN auto tools for top-quality parts and performance.

Let’s discover the auto parts that need CBN diamond cutting tools.

How do CBN and PCD Tools help in manufacturing auto parts?

Automotive brake disc

In the past, precision tools manufacturers used coated carbide and ceramic blades to process automotive brake discs. Even though they got the job done, it was terribly time-consuming, costs more, and had poor abrasive resistance.

When CBN inserts were introduced, manufacturers could reduce tool changing and production costs. CBN inserts come with ultra-high wear and impact resistance. So, it significantly helps to improve processing efficiency to make top-grade auto parts.

Automobile cylinder sleeve processing

With PCBN cutting tools, the automobile sleeve is more precise by controlling deformation when the cylinder block is under pressure. So, it reduces the wear rate between the cylinder block and the sleeve to improve the vehicle’s engine efficiency. Not to forget reducing fuel consumption and lower engine noise.

Automobile brake drum processing

Originally, brake drums consist of grey cast iron. The coating carbide tools or ceramic tools can only process 20 to 50 pieces of brake drums. Then, the production is interrupted to change into new tools which consume time.

With PCBN, especially CBN inserts, each edge can process 70 to 100 pieces of brake drums. A CBN insert uses a metal bond agent with super high hardness and wear resistance. So, it naturally improves production efficiency as it is an ideal choice for cast iron auto parts cutting.

Automotive transmission

The transmission housing is one of the most important parts of the car that assembles other auto parts to keep them in the right position. Therefore, it sets the accuracy of the auto parts box components, the performance, and the life of the installed machine.

So, as for the cast iron transmission housing blank machining with slag and pores, traditional processing methods poorly meet their processing requirements. With the CBN tool blade, easy loading and unloading are possible. Moreover, the blade can process 70 to 100 pieces of auto parts improving the processing efficiency by 50 to 70%.

Machining, milling, and ceramic finishing solution

PCD automotive tools, on the other hand, are used across the automotive production process beginning from the alloy wheels, cylinder blocks, cam, and crankshaft casing machining to milled, bored, and reamed gearbox housings.

On top of that, CBN cutting tools are the only viable solution for the finishing of new generation ceramic metal matric composite brake discs.

PCD and CBN tools for other auto parts

• Metal honing stones for the cylinder block and connecting rod
• Component grinding solution
• VVT gear
• Automobile box processing program
• Automotive piston, etc.

PCD and CBN Tools Supplier for Automotive Parts

All in all, it is crucial that an auto parts manufacturer has the perfect finishing to improve auto parts efficiency. Hence, consult us, the leading customized CBN inserts and PCD inserts supplier for your custom precision solutions.

Because we take great care in our precision tools manufacturing by always following DOE and ISO standards. We guarantee that our PCD PCBN cutting tools and services are nothing short of world-class.

How is a smartphone made?

Almost everyone in the world has a smartphone these days. But, not many are aware of how intricate and sophisticated it is to make. Here we uncover how PCD and CBN cutting tools come into action to make the world’s smartphones.

What is PCD Cutting Tools?

Polycrystalline Diamond (PCD) cutting tools or PCD carving tools can cut aluminum, brass and copper, graphite, and other materials like wood, plastic, and CFRP. Basically, PCD cutting tools have high abrasive resistance and high hardness which increases the durability of a phone equipment cutter.

What is CBN Cutting Tool?

Polycrystalline Carbon Boron Nitride (PCBN) also known as CBN cutting tools have high resistance to heat abrasion, perfect for fine finishing, and effective for tolerance control. This makes it suitable for iron, cast iron, sintered material, and other hardened materials (HRC50 and above).

PCBN cutting tools are typically applied with inserts and round tools which include endmills, reamers, and boring tools. CBN tools help reduce production costs due to more efficient processes of turning and milling.

PCD and PCBN Cutting Tools to Manufacture Phones

The diameter of PCD & PCBN tools is very small when manufacturing smartphones. Actually, they are the same diameter to machine glass and ceramic components in today’s devices.

Indeed, PCD and CBN cutting tools are high-precision tools that are effective in the manufacture of the latest smartphones.

For instance, the Apple iPhone 6 had the bevel on the aluminum housing machined using PCD profile cutters. On the iPhone X model, however, stainless steel was used in the housing frame so CBN cutters were used.

Hence, with rising demands on the design and technology of mobile phone manufacturers, the use of glass and ceramic also rises. The PCD and CBN cutting tools are more in need than ever in the phone manufacturing industry today. These materials offer many advantages including excellent reception quality.

On typical mobile phones, metal housings shield the wave transmission on wireless communications. This also protects from other integrated metal parts and ideally achieved with plastic strips.

However, phones with glass or ceramic housing do not require such shielding. Plus they are more sustainable than plastics and allow greater freedom of design. But, due to their brittleness, hardness, and low thermal conductivity, they require PCD and CBN cutting tools for perfect and clean finishing.

Therefore, the mobile phone manufacturing industry requires the highest precision cutting machinery and tools. PCD and CBN cutting tools are capable of producing very small internal radii and shoulders as well as tiny turned parts.

Custom CBN and PCD Tools Manufacturer

No matter the industry, machining processes require the highest precision for the best quality products. We are an ISO Certified Precision Tools manufacturer that has perfected our CBN and PCDtools manufacturing process.
